Wire Tracer WT58DL
Unique fast fault detection red light function
Wire Tracer WT58DL is suitable for POE switches, routers, fiber modems and other network devices. Supports tracing and testing of telephone lines, coaxial video cables and various other cables. WT58DL is equipped with RJ45 cable connector tester and AC voltage detection (above 48V). It also has a unique red light function to provide enhanced visual feedback for cable tracing and fault detection. The fast breakpoint locator further simplifies maintenance tasks, making WT58DL a must-have tool for professionals.
Functions
| WT58DL | |
| Transmit signals | Digital Signal (no interference, no signal) |
| Internet Switch | Internet Switch/Router /Modem |
| Wire Track | Directly track wire type: RJ45,RJ11 and other Weak Current Electric Wires |
| Sequence collation | Open circuit, Short circuit, detection of cable line sequence |
| Test the positive and negative poles of the wire | √ |
| Telephone Line Test | Identify the state of the working telephone line (clear, ring, busy) |
| Continuity | Judge continuity of the cables or wires |
| POE Switch Withstand Voltage | Wire track for POE Switch when the DC Voltage is less than 60V |
| Switch port sequence collation | Emitter directly check the sequence collation for Switch port Cables |
| Red Light | √ |
| Transmitting signal distance | 0-300m |
| Batteries | 9V 6F22(1PCS for Transmitter, 1PCS for Receiver) |
| Size | Receiver:190*40*23(mm) / Emitter: 140*60*25(mm) |
| Weight | About 425g |
| Safety Level | CE(EMC) |
