NTC Sensor Anemometer AM620
Anemometer with five selectable wind speeds
Anemometer AM620 has a measurement range of 0.8m/s to 30m/s. It has a resolution of 0.1m/s and can provide accurate wind speed readings. It can measure temperatures from -10 to 60°C, making it ideal for heating systems. The anemometer also offers five wind speed type adjustments to meet different wind speed test requirements. The device’s 0.4 second sampling rate and five wind speed unit conversion functions make measurement more efficient and convenient. The use of NTC negative temperature coefficient sensors ensures accurate temperature and wind speed measurements.
Functions
| Wind speed range | 0.8~30.00 m/s |
| Resolution | 0.1m/s |
| Accuracy | +(3.0%+0.3m/s) |
| Wind rating | 0~12 level |
| Accuracy | ±1 |
| Temperature measurement range | 0°C~70°C/-32°F~158°F |
| Accuracy | +1.5°C (±2.7°F) |
| LCD | Four-digit display |
| sensor | NTC negative temperature coefficient senso |
| Sampling rate | 0.5 seconds |
| Five wind speed unit conversion | m/s, km/h,ft/min,knots,mph |
| Backlit display | √ |
| Maximum measurement indication | √ |
| power supply | 3*1.5V AAA |
| physical dimension | 154*59*30(mm) |
| weight | 108g (including battery) |
Factory Showcase
Mestek achieves high standards and high consistency in product inspection and calibration through precise machinery and a clean environment.
