DM97A+ is a high-precision multimeter with 10000 counts. It supports 600V DC/AC voltage measurement. It provides K-type temperature thermocouples and can measure temperatures up to 1000℃. It is equipped with True-RMS measurement function to ensure accurate AC and DC signal measurement. DM97A+ also has continuity measurement function. When the circuit is detected to be open or closed, it provides audible and visual alarms to enhance safety and convenience.
| DC Voltage | 1V/10V/100V/600V | ±(0.8%+3) |
| AC Voltage | 1V/10V/100V1600V | ±(0.8%+10) |
| DC Current | 100mA/600mA | ±(3.0%+10) |
| AC Current | 100mA/600mA | ±(3.0%+10) |
| Resistance | 10kΩ/100kΩ/10MΩ/100MΩ | ±(1.0%+5) |
| Capacitance | 100nF/1μF/10μF/100μF/1mF/10mF/100mF | ±(4.0%+10) |
| °C/°F | 20°C~1000°C/-4°F-1832°F | ±(2.0%+2) |
| Manual/Auto/Smart | Manual/Auto | |
| Display | 10000 Counts | |
| ACV/ACA T-RMS | √ | |
| °C/°F | √ | |
| Continuity | Sound And LED Alarm | |
| Diode Test | √ | |
| Batteries | 2*1.5V AA | |
| Size | 190*89*50(mm) | |
| Weight | About 500g | |
| Safety Level | IEC61010-1:2020 CAT Ⅲ 1000V | |
| Standard Accessories | Multimeter-Probe-K Type Thermocouple-Batteries-User Manual-Color Box |
