The DC voltage measurement range of the digital multimeter DM91 is 200mV~600V. It is a non-contact AC voltage measurement multimeter. It can automatically measure diodes and continuity, and can also measure battery pressure. With the manual range design, it can measure the voltage and current range more accurately.
| DC Voltage | 200mV/2V/20V/200V/600V | ±(0.5%+3) |
| AC Voltage | 200V/600V | ±(0.8%+3) |
| DC Current | 2000uA/200mA/10A | ±(1.5%+2) |
| Resistance | 200Ω/2kΩ/20kΩ/200kΩ/20MΩ | ±(1.0%+2) |
| Continuity/Diode Check | Auto check diode or continuity | |
| Non-contact AC Voltage Detection | Yes | |
| Battery VoltageTesting | 1.5V/9V | |
| Display | 6000 counts | |
| Manual/Auto/Smart | Manual | |
| Auto Power off | √ | |
| Data Hold | √ | |
| AC Voltage Frequency | √ | |
| Batteries | 2*1.5V AAA | |
| Size | 150*70*50(mm) | |
| Weight | About 195g | |
| Safety Level | EN61010-2-033,CAT Ⅲ 600V |
