DM100B
1000V DC voltage measurement digital multimeter
DM100B is a multi-function digital multimeter with 10000 counts and high-precision measurement functions. Its maximum resistance measurement is 100MΩ resistance measurement, suitable for a wider range of electrical system tests. Supports ACV/ACA true RMS measurement, non-contact AC voltage detection. It has diode and continuity automatic detection functions. DM100B also provides fuse blown warning and neutral and live wire identification to ensure test safety.
Functions
| DC Voltage | 1000mV/1V/10V/100V/1000V | ±(0.5%+3) |
| AC Voltage | 1000mV/1V/10V1100V1750V | ±(1.0%+5) |
| DC Current | 9999uA/600mA/10A | ±(0.8%+3) |
| AC Current | 9999μA/600mA/10A | ±(1%+3) |
| Capacitance | 100nF/1000nF/10uF1100uF/1000uF/6mF | ±(3.5%+15) |
| Resistance | 1000Ω/10kΩ/100kΩ/1000kΩ/10MΩ | ±(0.8%+3) |
| Display | 10000 Counts | ±(1%+3) |
| ACV/ACA TRMS | √ | |
| ACV(bandwidth) | 1kHz | |
| Hz | 10MHz | |
| Ω | 100MΩ | |
| Continuity | Sound And LED Alarm | |
| Diode Test | √ | |
| Batteries | 2*1.5V AA | |
| Size | 190*89*50(mm) | |
| Weight | About 500g | |
| Safety Level | IEC61010-1:2020 CAT Ⅲ 1000V | |
| Standard Accessories | Multimeter-Probe-K Type Thermocouple(optional) | |
| Batteries-User Manual-Color Box |
