IR05B
Dual laser infrared thermometer -40~2000°C (-40~3632°F)
Infrared thermometer IR05B, measuring temperature range -40 ~ 2000 ° C (-40 ~ 3632 ° F). It has dual laser function, the maximum measurement temperature reaches 2000 ° C, very suitable for industrial fields. Built-in high-precision chip, with K type thermocouple, the measurement speed is only 0.5 seconds. The temperature warning can be set manually. When the measured temperature exceeds the set alarm value, an alarm indication will appear on the instrument screen.
Functions
| Temperature range | -40~2000°C(-40~3632°F) |
| Indicator | VA reverse display color screen |
| D:S | 50:01:00 |
| Spectral response | 8~14um |
| Resolution ratio | 0.1°C/0.1°F |
| Emissivity | 0.10~1.00 |
| Laser | <1mw/620~690 nm Grade 2 |
| Response time | <0.5S |
| Automatic shut-down | About 35 seconds |
| llumination accuracy | -40~0°℃ ±(3°C/6°F) |
| 0-800“C+(1.5%+2°C) | |
| 800~1200°C±(3%°C) | |
| 1200°C~2000°C(5%°C) | |
| K-type temperature range | -10°C~500°C(14°F~932°F) |
| K-type accuracy | ±(1.5% + 2°C/4°F) |
| Operational environment | 0~50°C/10%-90%RH |
| Storage temperature | -20°C~60°C |
| Size | 180x120x60mm |
| Power Supply | 2×1.5V AA battery |
| Weight | About 265g (excluding battery) |
